Lithium Trolling Motor & Marine Battery
Trolling motor batteries are specially designed batteries for a boat trolling motor. The purpose behind them is to provide electricity over a more extended period of time when slow trolling through fishing areas. In contrast, boat & marine starting batteries are engineered to deliver high-cranking amps (CA) and cold cranking amps (CCA) for quick starting the engine ignition.
Developed with the cutting-edge lithium iron phosphate (LiFePO4) technology, the lithium ion trolling motor & marine batteries are born with dual purposes of both starting and outputting long lasting power for trolling motor & marine. Compared with conventional lead acid AGM or GEL battery, lithium batteries have overwhelming advantages in cycle life, energy density, charging speed and many more.
Lithium Battery VS Lead acid Battery
Why you need to change your clumsy lead acid batteries to lithium
| Product Photo |
|
|
| Energy Density | 200Wh/kg | 40Wh/kg |
| Weight | 10Kg (12.8V 100Ah*1) | 30Kg (12V 100Ah*1) |
| Life Cycles@100%DOD | 2000+ cycles | 300-500 cycles |
| Discharge Depth | 100% | 70% |
| Charging Time | 2-3h | 8-10h |
| Self-discharge | 1-1.5%/m | 3%/m |
| Eco-Friendly | Yes (Meet RoHS) | No (Not meet RoHS) |
| Customization | Yes (LCD/Bluetooth/USB/Thermal) | No |
Longer Battery Lifespan
Lithium LiFePO4 batteries poccess a considerably longer lifespan compared to traditional lead-acid AGM / Gel batteries commonly used in trolling motors & leisure marine. Lithium batteries can cycle up to 10x longer than lead-acid batteries. While lead-acid batteries may last around 300 to 500 charge cycles, lithium batteries can endure upwards of 2000 charge cycles. Specific types of lithium batteries consistently reach over 3,500 cycles.
Lower TOC (Total Operation Cost)
Although lithium batteries have a high upfront cost, compared to frequent lead-acid battery replacements, a lithium battery pays for itself over its lifetime. Not only does the investment in a lithium battery pay for itself over time, but big savings can be made in the way of reduced energy bills, maintenance costs, and possible repairs cost. The extended lifespan of a lithium battery translates to years of reliable service on the fishing time without the hassle of frequent battery replacements, providing fishers with peace of mind and cost savings in the long run.
High Energy Density
Equipping a lithium battery into a trolling motor or leisure marine enables the cart to significantly increase its weight-to-performance ratio making makes it longer to enjoy the fishing time. Lithium batteries are significantly lighter than lead-acid batteries, and only 1/3 the weight of a traditional lead-acid battery. The higher energy density means that you can run longer time on water. For example, if your trolling motor draws a current of 54A at full speed. A 100Ah lithium battery will last for 1.85 hours or 1 hour 51 minutes on that trolling motor at full speed, while the same 100Ah lead acid battery can ony run about half an hour or less.
Much Faster Charging & Quicker Recovery After Discharge
Lithium batteries feature rapid charging capabilities, allowing the batteries fully charged by the alternator quickly. Besides, lithium batteries recover to its performing voltage quicker after discharge to make sure it providing consistant power to the trolling motors.
Eco Friendly
As sustainability becomes increasingly important across all industries, golfers are also seeking eco-friendly solutions for their equipment. Lithium batteries, particularly lithium iron phosphate batteries, are more environmentally friendly and put less strain on the environment than lead-acid batteries due to their non-toxic chemistry and higher energy efficiency. They take significantly less time to fully charge, resulting in using less energy. Additionally, lithium batteries are recyclable, further reducing their environmental impact and supporting the shift towards greener practices in golf course management.
Why Choose Us
Genuin Material & Solid Substance
Only use world top tier A grade lithium cells and automotive grade BMS.
Strict Quality control
All the cells are graded & grouped before assembly, and all battery packs are 100% passed aging test.
20+ Years of Deep Technology Accumulation
Our major team members have more than 20 years of experience in lithium battery industry.
Worry-Free After Sale Services
We provide worry-free after sales service and technical support for you to focus on marketing.
Our Lithium golf cart battery advantages
Often Asked Questions
1.Are lithium batteries worth it for trolling motor?
A lifespan of a lithium marine battery can last up to 10 times longer than traditional lead-acid batteries—ultimately saving money in the long run.
2. What lithium battery capacity do I need for my trolling motor?
Choosing the right LiFePO4 Battery for your trolling motor according to below table.
| Voltage of Motor | Motor Thrust | Recommended Max Amp of Batteries |
|---|---|---|
| 12V | 20 ~ 30 lb | 50A |
| 12V | 30 ~ 70 lb | 100A |
| 24V | 70 ~ 100 lb | 100A |
| 36V | 100 ~ 120 lb | 100A |
Yes, you need a charger that's compatible with LiFePO4 lithium. Many lead acid chargers aren't compatible because they don't put out the right amount of volt t .
3. How long will a 100Ah lithium battery run a trolling motor?
For example, if your trolling motor draws a current of 54A at full speed. A 100Ah lithium battery will last for 1.85 hours or 1 hour 51 minutes on that trolling motor at full speed.
4. Can I use a car battery for a trolling motor?
Car batteries are used for starting the engine in a short period of time (2-3s) with a very high cranking ampers. While trolling motor needs a constant ampers from the battery. Thus car batteries can not be used for a trolling motor and you need a deep cycle batteries wheather lithium or lead acid.
5. Is 50Ah enough for a 24V trolling motor?
For 24V trolling motor systems: Light users 24v 50AH. Moderate users 24v 80AH.
We're well-known as one of the leading lithium trolling motor battery manufacturers and suppliers in China. Please feel free to buy high quality lithium trolling motor battery made in China here from our factory. For price consultation, contact us.
