Our LFP20L-BS 12V 12Ah lithium motorcycle battery can replace batteries in Harley Davidson and delivers robust cranking ampere. Its CCA can be 720A which can start a SUV with ease. It is ultra light-weighted and the built-in BMS will protect the battery from over charge, over discharge, over temperature and short circuit.
Specifications & Parameters
|
Model No. |
LFP20L-BS |
|
|
Nominal Voltage |
12.8V |
|
|
Nominal Capacity |
12Ah |
|
|
Cold Cranking Amps |
720A |
|
| Continuous Discharge Current | 150A | |
| Pulse Discharge Current (5s) | 900A | |
|
Dimensions |
Length |
175±2mm |
|
Width |
87±2mm |
|
|
Total Height (w/ terminal) |
155±2mm |
|
|
Weight |
Approx. 1.8KG |
|
|
Cell Type |
High Rate Pouch Cell |
|
|
Polarity |
-/+ |
|
|
Terminal Type |
Copper |
|
|
Enclosure Material |
ABS |
|
|
LCD Display |
Yes |
|
|
Main Switch |
No |
|
Lithium ion Battery VS Lead Acid AGM Battery
Our Lithium motorcycle Battery Advantages
Other Available Models
|
Model |
Voltage (V) |
Capacity (Ah) |
CCA (A) |
Dimensions L*W*H (mm) |
Weight (Kg) |
||
|
LFP4L-BS |
12.8 |
2 |
160 |
113 |
70 |
89 |
0.52 |
|
LFP5L-BS |
12.8 |
3 |
180 |
113 |
70 |
105 |
0.57 |
|
LFP7S |
12.8 |
4 |
260 |
113 |
70 |
105 |
0.67 |
|
LFP7L-BS |
12.8 |
4 |
260 |
113 |
70 |
130 |
0.82 |
|
LFP7B-4 |
12.8 |
4 |
260 |
150 |
65 |
93 |
0.85 |
|
LPF7A-BS |
12.8 |
4 |
260 |
150 |
87 |
93 |
0.86 |
|
LFP7-A |
12.8 |
6 |
350 |
135 |
75 |
133 |
0.9 |
|
LFP9-BS |
12.8 |
6 |
350 |
150 |
87 |
105 |
2.0 |
|
LFP9-B |
12.8 |
6 |
350 |
135 |
75 |
133 |
2.0 |
|
LFP9B-4 |
12.8 |
6 |
350 |
150 |
68 |
105 |
2.0 |
|
LFP10S |
12.8 |
8 |
420 |
150 |
87 |
93 |
2.9 |
|
LFP12A-BS |
12.8 |
8 |
450 |
150 |
87 |
105 |
2.9 |
|
LFP12S |
12.8 |
8 |
450 |
150 |
87 |
110 |
2.9 |
|
LPF12-BS |
12.8 |
8 |
450 |
150 |
87 |
130 |
3.0 |
|
LFP12B-4 |
12.8 |
8 |
450 |
150 |
69 |
130 |
3.0 |
|
LFP14S |
12.8 |
8 |
480 |
150 |
87 |
110 |
3.1 |
|
LFP14B-4 |
12.8 |
8 |
480 |
150 |
70 |
145 |
3.1 |
|
LFP14L-BS |
12.8 |
8 |
520 |
150 |
87 |
145 |
4.1 |
|
LFP19L-BS |
12.8 |
12 |
560 |
182 |
79 |
171 |
4.4 |
|
LFP20L-BS |
12.8 |
12 |
620 |
175 |
87 |
155 |
4.4 |
|
LFP30L-BS |
12.8 |
20 |
720 |
168 |
127 |
177 |
7.3 |
Lithium motorcycle battery applications
Our Lithium Battery Factory
Our Honor & Certificates
FAQ
Q1: Can they be drop-in replacement of the lead acid AGM batteries?
A: Yes, we have full range of lithium batteries can drop-in replace the original lead acid AGM battery.
Q2: Does the lithium motorcycle battery have BMS ?
A: Yes, there is built-in BMS inside to protect battery from over-charging, over-discharging, over-heat and short circuit.
Q3: What is your MOQ for 12V 12Ah lithium motorcycle battery and do you provide private labeling service?
A: Our MOQ is 50pcs/model and we provide private labeling service and can design the package with your logo free of charge.
Q4: Do you provide samples for testing?
A: Yes, samples are available for testing.
Q5: Do you accept OEM my private brand? Can I have special color for the battery?
A: Yes, we can make private labelling service. Our standard color is black and we can make special color.
Q6: What is your warranty for 12V 12Ah lithium motorcycle battery?
A: 3 years
Q7: Can you provide drop shipment for the lithium motorcycle batteries?
A: Yes, we can provide DDP drop shipment.
